Features
|
Specifications
Technical Specifications
| Frequency Range | 350-400 MHz |
| Number of Channels | 260 (64 for basic models) |
| Number of Zones | 128 (4 for basic models) |
| Channel Spacing – Analogue – Wide/Mid/Narrow | 30 kHz/25 kHz/20 kHz/12.5 kHz |
| Channel Spacing – Digital – Wide/Narrow | 12.5 kHz/6.25 kHz |
| Battery Life | With KNB-45L: ± 14.5 h (TDMA) With KNB-53N: ± 10.0 h (TDMA) With KNB-69L: ± 19.0 h (TDMA) – 5-5-90 – |
| Frequency Stability | ± 0.5 ppm (-30 °C to + 60 °C) |
| Operating Temperature Range | -30 °C to + 60 °C |
| Operating Voltage | 7.5 V DC ± 20% |
| Dimensions | With KNB-45L: 54.0 x 123.0 x 33.5 mm With KNB-53N: 54.0 x 123.0 x 33.5 mm With KNB-69L: 54.0 x 123.0 x 37.5 mm Radio only: 54.0 x 123.0 x 33.5 mm – Projections not included – |
| Weight (net) | With KNB-45L : 295 g With KNB-53N : 365 g With KNB-69L : 310 g Radio only : 175 g |
Receiver Specifications
| Adjacent Channel Selectivity (Analogue) | 74 dB at 25 kHz 68 dB at 12.5 kHz |
| Audio Output | 1 W (Internal) |
| Intermodulation | 65 dB |
| Sensitivity (Analogue) – EIA 12 dB SINAD | 0.22 µV at 12.5 kHz 0.26 µV at 25 kHz |
| Sensitivity (Digital) | 5% BER: 0.20 µV at 12.5 kHz 1% BER: 0.28 µV at 12.5 kHz 3% BER: 0.24 µV at 12.5 kHz 3% BER: 0.19 µV at 6.25 kHz |
| Spurious Reponse Rejection (Analogue) | 70 dB |
Transmitter Specifications
| RF Power Output | 5 W / 4 W / 1 W |
| Audio Distortion | 2% |
| FM Hum & Noise | Analog @ 12.5 kHz : 40 dB Analog @ 25 kHz : 45 dB |
| Spurious Emission | -70 dB |
Accessories
KNB-84L
Li-ion Battery Pack (7.4V/1900mAh) [IP67]
KSC-35S
Rapid Charger (for Li-ion KNB-45L/69L/84L)
KRA-22/23
VHF/UHF Low Profile Helical Antenna
KMC-45D
Speaker Microphone
KHS-31C
C-Ring PTT Ear Hanger Headset
KSC-43
Rapid Charger (for Li-ion KNB-45L/69L/84L & NiMH KNB-29N/53N )
Use below photo data.
KRA-26/27
VHF Helical Antenna UHF Whip Antenna
KHS-26
Earbud In-line PTT Headset
KBH-10
Belt Clip
KVC-22
DC Vehicular Charger Adapter
KRA-41/42
VHF/UHF Stubby Antenna
KHS-27A
D-Ring In-line PTT Headset
