The NX-5000 Series offers unsurpassed interoperability for a wide variety of users as it supports three digital CAIs — NXDN, DMR and P25 (Phase 1 & 2) — plus FM analog in a single radio. Best of all, a desired CAI can be selected at will, giving you the freedom to migrate at your own pace — whether you are intent on going fully digital, undecided about which digital system to pick, or just wanting to maintain both digital and analog for a while. An NX-5000 radio can simultaneously support two digital protocols plus analog, offering the following combinations: FM/DMR/ NXDN, FM/NXDN/P25, and FM/DMR/P25.
- NXDN:
- A desired CAI can be selected at will – whether you are intent on going fully digital, undecided about which digital system to pick, or just wanting to maintain both digital and analog for a while.
The NXDN air interface can fit into the very narrow 6.25 kHz bandwidth using FDMA technology. Ensuring spectrum efficiency, wide coverage and virtually unlimited scalability, it provides for nationwide expansion: Type-C Trunking Gen2 offers enhanced features, flexibility and performance, linking up to 1,000 sites or 24 networks.
- DMR:
- For simple conventional communications, making use of existing infrastructure, DMR is an excellent, cost-effective solution. Being energy-efficient, it offers longer battery life. And thanks to 2-slot TDMA, it is possible to obtain 2 talk paths within an analog 12.5 kHz bandwidth, thus doubling the capacity. The NX-5000 Series supports Tier II conventional mode.
- P25:
- This digital CAI ensures interoperability among public safety agencies in North America, Australia and New Zealand. The NX-5000 Series is compatible with Phase 1 (conventional and trunked), and Phase 2 (trunked).
Choose between two portable configurations – one without a numeric keypad and the other with numeric keypad (16-key model). Both styles feature the 4-way Directional-pad (D-pad) and 2-position lever switch.
A 1.74-inch (240 x 180 pixel) 65,536-color Transflective LCD, capable of displaying a multi-line text and colored icons, can be viewed clearly in direct sunlight or in the dark, even while wearing polarized sunglasses.
In addition to sophisticated sound analysis and optimization technologies, these radios feature Active Noise Cancelling based on leading-edge digital technology to offer clear communications even in very noisy environments.
During the development stage, NX-5000 Series radios go through a number of stringent tests as shown below. As a result, the portable radios complying with IP67/68 immersion standards offer max. 2-hour protection at a depth of 1 meter*, while the mobile radios comply with IP54/55 dust/water ingress protection standards.
*Applies for IP68
Hands-free operation is vital for many NX-5000 users. The radios’ built-in Bluetooth® module is compatible with Headset and Serial Port Profiles (ver. 3.0) and keeps your hands free.
Featuring an integrated GPS module and antenna, NX-5000 portable radios can transmit positional data, enabling effective management when used with tracking applications like KAS-10 software. Mobile models can support GPS with the optional KRA-40G.
For storing voice and data, memory capacity can be increased up to a huge 32GB on a microSD card.*
* Purchase a card separately
Secure communications are an essential requirement, especially for public safety applications.
NX-5000 radios are equipped with 56-bit key Data Encryption Standard (DES) encryption. For even higher protection the radios can support 256-bit Advanced Encryption Standard (AES) encryption with optional module.
Man-down Detection, Stationary Detection, or Motion Detection will be automatically engaged when the embedded acceleration and tilt sensors detect unusual behavior. Lone Worker function automatically places the radio in Emergency Mode if it is not operated for a certain period of time.
The bright orange Emergency Button is located at the top (portables) or front (mobiles) of the radio for high visibility and instant access when needed.
Extend battery lifetime and ensure that the batteries are optimally maintained. The system comprises High-capacity Li-Ion Battery Series (KNB-L1/L2/L3), Intelligent Charger (KSC-Y32), and Battery Reader software (KAS-12).
* Up to 1,000 batteries can be managed at a time (requires additional option).
* Long Life Charging Mode: stops recharging at 80% capacity to extend life.
* Deterioration (end-of-life) notification
High-capacity Li-Ion Battery Series
Suited for distribution and courier services, this is the simplest configuration. The detachable front control panel of the NX-5700/5800 is used as a Remote Control Head.
Intelligent Charger KSC-Y32
Battery conditions are displayed in color illuminated indicators on the charger, which are also displayed on a connected PC with the same color scheme.
Color-coordinated patterns provide users with at-a-glance information for comprehensive battery management.
Conceptual Diagram of the Intelligent Battery Management System
Battery conditions are displayed in color illuminated indicators on the charger, which are also displayed on a connected PC with the same color scheme.
Color-coordinated patterns provide users with at-a-glance information for comprehensive battery management.
・Gen2 & NXDN® Conventional/Type-C Trunking Protocol
・DMR Tier II Conventional
・P25 Conventional/Trunking (Phase 1/Phase 2)
– FM Analog Conventional & LTR Zones
– Color GUI and Multi-line Text Display
– 1,000 mW Speaker Audio (@8 Ω, 5% distortion)
– 4-way Directional-pad (D-pad) and 2-Position Lever Switch
– 6 Front & 2 Side PF keys
– 12-Key Keypad Models Available
– Emergency / AUX Key
– MDC-1200
– FleetSync®/II
– Maximum of 4,000 CH/Radio capacity, 512 CH/Zone, 128 Zones
– Intrinsically Safe Option
| Portable Radios | ||||
|---|---|---|---|---|
| GENERAL | NX-5200 | NX-5300 | NX-5400 | |
| Frequency Range | 136-174 MHz | Type 1: 450-520 MHz Type 2: 380-470 MHz | RX: 763-776, 851-870 MHz TX: 763-776, 793-806, 806-825, 851-870 MHz | |
| Max. Channels Per Radio | 1024 (Up to 4000 channels with option) | |||
| Number of Zones | 128 | |||
| Max. Channels Per Zone | 512 | |||
| Channel Spacing | Analog | 12.5/15/20/25*/30* kHz | 12.5/25* kHz | 12.5/25 kHz |
| Digital | 6.25/12.5 kHz | 6.25/12.5 kHz | 12.5 kHz (6.25 kHz) | |
| Power Supply | 7.5 V DC ±20% | |||
| Battery Life (5-5-90/10-10-80 duty cycle) | KNB-L1 (2,000mAh) | 10 hours / 6.5 hours | ||
| KNB-L2 (2,600mAh) | 12.5 hours / 8.5 hours | |||
| KNB-L3 (3,400mAh) | 17 hours / 11 hours | |||
| Operating Temperature | -22°F to +140°F (-30°C to +60°C) | |||
| Frequency Stability | ±2.0 ppm | ±1.0 ppm | ±1.5 ppm | |
| Dimensions (W x Hx D) Projections Not Included | KNB-L1 (2,000mAh) | 2.28 x 5.47 x 1.52 in. (58 x 139 x 38.8 mm) | ||
| KNB-L2 (2,600mAh) | 2.28 x 5.47 x 1.65 in. (58 x 139 x 41.8 mm) | |||
| KNB-L3 (3,400mAh) | 2.28 x 5.47 x 1.86 in. (58 x 139 x 47.2 mm) | |||
| Weight | KNB-L1 (2,000mAh) | 15.52 oz (440 g) | ||
| KNB-L2 (2,600mAh) | 16.57 oz (470 g) | |||
| KNB-L3 (3,400mAh) | 17.98 oz (510 g) | |||
| RECEIVER | NX-5200 | NX-5300 | NX-5400 | |
| Sensitivity | NXDN 6.25 kHz Digital (3% BER) | 0.20 μV | – | |
| NXDN 12.5 kHz Digital (3% BER) | 0.25 μV | – | ||
| P25 Digital (5%BER) | 0.25 μV | |||
| P25 Digital (1%BER) | 0.40 μV | |||
| Analog (12dBSINAD) | 0.25 μV | |||
| Selectivity | P25 Digital | 60 dB | ||
| Analog @ 12.5 kHz | 67 dB | 64 dB | ||
| Analog @ 25 kHz | 73 dB | |||
| Intermodulation | 75 dB | |||
| Spurious Rejection | 85 dB | |||
| Audio Distortion | 3% | |||
| Audio Output Power | 500 mW/8 Ω (3% Distortion) / 1,000 mW /8 Ω (5% Distortion) | |||
| TRANSMITTER | NX-5200 | NX-5300 | NX-5400 | |
| RF Power Output Power | 5 to 1 W | 3 to 1 W | ||
| Spurious Emission | -70 dB | |||
| FM Hum & Noise | Analog @ 12.5 kHz | 40 dB | ||
| Analog @ 25 kHz | 45 dB | |||
| Audio Distortion | 2% | |||
| Emission Designator | 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, 8K10F1W, 8K30F1E, 8K30F1D, 8K30F7W, 4K00F1E, 4K00F1D, 4K00F7W, 4K00F2D | 16K0F3E, 14K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, 8K10F1W, (8K30F1E, 8K30F1D, 8K30F7W, 4K00F1E, 4K00F1D, 4K00F7W, 4K00F2D) | ||
*25 and 30 kHz are not included in the models sold in the USA or US territories. Analog measurements made per TIA 603 and specifications shown are typical. Digital measurements made per TIA 102CAAA and specifications shown are typical.
Details and timing of firmware and software updates are subject to change without notice. Specifications are subject change without notice, due to advancements in technology.
| Description | Release Date | File Download | File Size(KB) |
|---|---|---|---|
| English Instruction manual LIST | 2021 | > Download > View  | 98KB |
| English NX-5200,5300,5400 USER MANUAL R2.6 | 2018 | > Download > View | 13,310KB |
| English NX-5200,5300,5400 USER MANUAL R3.0 | 2019 | > Download > View | 13,366KB |
| English,French,Spanish NX-5200,5300,5400 USER GUIDE | 2015 | > Download > View | 5,061KB |
| English,French,Spanish NX-5200/5300/5400 Quick reference card | 2021 | > Download > View | 860KB |
| English,French,Spanish USER GUIDE_K type | 2020 | > Download > View | 5,896KB |
| English,French,Spanish,German,Italian,Portuguese,Dutch,Danish,Swedish,Finn,Nor Simple guide | 2020 | > Download > View | 11,231KB |
| English,French,Spanish,German,Italian,Portuguese,Dutch,Greek,Tu NX-5200,5300 (E) USER GUIDE | 2018 | > Download > View | 25,231KB |
| English,French,Spanish,German,Italian,Portuguese,Dutch,Greek,Turkish Safety Manual | 2018 | > Download > View | 844KB |
| English,French,Spanish,German,Italian,Portuguese,Dutch,Greek,Turkish USER GUIDE | 2023 | > Download > View | 11,640KB |
| English,French,Spanish,German,Italian,Portuguese,Dutch,Greek,Turkish USER GUIDE_E type | 2020 | > Download > View | 12,444KB |
| French NX-5200,5300,5400 USER MANUAL R2.6 | 2018 | > Download > View | 13,341KB |
| French NX-5200,5300,5400 USER MANUAL R3.0 | 2019 | > Download > View | 13,397KB |
| Spanish NX-5200,5300,5400 USER MANUAL R2.6 | 2018 | > Download > View | 13,330KB |
| Spanish NX-5200,5300,5400 USER MANUAL R3.0 | 2019 | > Download > View | 13,383KB |
KNB-L1/L2/L3
LI-ION BATTERY PACK (IP67/68 immersion)
KNB-N4
Ni-MH BATTERY PACK (IP67/68 Immersion)
KBP-8
BATTERY CASE (12AA Alkaline Battery)
KSC-32/32S
RAPID CHARGER
KSC-326/326S
MULTIPLE CHARGER (6-unit Rapid Rate)
KRA-22
VHF HELICAL ANTENNA (Low Profile)
KRA-23
UHF HELICAL ANTENNA (Low Profile)
KRA-26
VHF HELICAL ANTENNA (Standard Length)
KRA-27
UHF WHIP ANTENNA (Standard Length)
KRA-32
700/800 MHz WHIP ANTENNA
KRA-41
VHF STUBBY ANTENNA
KRA-42
UHF STUBBY ANTENNA
KMC-72
SPEAKER MICROPHONE (IP67)
KMC-70/70GR
SPEAKER MICROPHONE (IP68)
IPX8, 3 Buttons on top
2 Microphone for noise cancel feature by radio’s DSP
KWD-AE30/AE31
SECURE CRYPTOGRAPHIC MODULE
KPG-180AP
OTAP MANAGER
KBH-11
BELT CLIP
